-1.56-
1.35.4 Erasing contents of a radar map
1. Press the NAV MENU, [1] and [9] key to display MAP ERASE menu.
2. Press a wanted number key twice to select OFF or ALL, followed by the ENTER key.
[MAP ERASE]
1 [RADAR MAP]
2 DANGER HIGHLIGHT OFF/ALL
3 COAST LINE OFF/ALL
4 MARK OFF/ALL
5 NAV LINE OFF/ALL
6 PROHIBITED AREAS OFF/ALL
7 BUOY OFF/ALL
8 CONTOUR LINE OFF/ALL
9 WPT MARK OFF/ALL
3. Press the NAV MENU key to leave the menu.
[NAV INFOMATION 1]
1 [RADAR MAP]
2 SELECT NAVAID GPS+LC/DEAD RECKONING
3 OWN SHIP POSN OFF L/L
4 POSN xx
° xx.xxx
N/S
xxx
° xx.xxx
E/W
5 +CURSOR DATA OFF/ L/L
6 WPT DATA OFF/REL/TRUE
7 [NAV LINE]
8 [WAY POINT]
9 WIND DATA OFF/ ON
0 [NAV INFOMATION 2]
Press [NAV MENU\] key.
[NAV INFOMATION 2]
1 [NAV INFOMATION 1]
2 WIND GRAPH OFF/ON
3 WIND UNIT m/s /KT
4 CURRENT DATA OFF/ON
5 CURRENT GRAPH OFF/ON
6 DEPTH DATA OFF/ON
7 DEPTH GRATH OFF/ON
8 DEPTH SCALE 10/20/50/100/
200/500
9 DEPTH UNIT *1 m/ft
0 [NAV INFOMATION 3]
[NAV INFOMATION 3]
1 [NAV INFOMATION 2]
2 WATER TEMPERATUDE *1 OFF/ON
3 DATE OFF/UTC/LOCAL +00:00H
4 USED WPL*
NAV LINE/WP
[RADAR MAP]
1 [NAV INFOMATION 1]
2 MAP OFF/ON
3 MAP NO. MAP xx
MAP LIST xx xx
xx xx xx xx
xx xx xx xx
4 NAV DATA POSN
5 ALIGN +CURSOR DATA OFF/ON
6 MARK ENTRY MODE CURSOR/ L/L /OWN SHIP POSN
7 [ENTER MAP]
8 [MAP DISP SELECT]
9 [MAP ERASE]
[ENTER MAP]
1 [RADAR MAP]
2 ENTEA MAP MAP xx
9 ERASE MAP MAP xx
[WAY POINT]
1 [NAV INFOMATION 1]
2 WPT MARK
OFF/ON
3
4 WPT LINE
OFF/ON
5 WPT NO. OFF/ON
6
7
8 ARRIVAL ALARM
OFF/ON
x.xxNM
[MAP DISP SELECT]
1 [RADAR MAP]
2 DANGER HIGHLIGHT OFF/ON
3 COAST LINE
OFF/ON
4 MARK OFF/ON
5 NAV LINE OFF/ON
6 PROHIBITED AREAS OFF/ON
7 BUOY
OFF/ON
8 CONTOUR LINE OFF/ON
9
[MAP ERASE]
1 [RADAR MAP]
2 DANGER HIGHLIGHT OFF/ALL
3 COAST LINE
OFF/ALL
4 MARK OFF/ALL
5 NAV LINE OFF/ALL
6 PROHIBITED AREAS OFF/ALL
7 BUOY
OFF/ALL
8 CONTOUR LINE OFF/ALL
[NAV LINE]
1 [NAV INFOMATION 1]
2 NAV LINE
OFF/ON
3
4 NAV WIDTH
OFF/ON
x.xxNM
5 WPT NO. OFF/ON
6
7
8 ARRLVAL ALARM
OFF/ON
x.xxNM
9 TURNING LINE OFF/ON/REVISED
*: R-type only
*1: Fishing mode only (one type of R-type)
