Furuno FR-2105-B - Manual (Page 32)

-1.15-
[RADAR MENU] key
[FUNCTIONS 1]
1 TARGET TRAILS
2 TARGET ALARM 1 or 2
3 ORIGIN MARK 1 to 10
4 INDEX LINES
5 ZOOM*
6 PULSE WIDTH
7 INT REJECT
8 ARPA
9 VIDEO PLOT
0 [FUNCTION 2]
[0] key [1] key
[FUNCTIONS 2]
1 [FUNCTIONS 1]
2 BKGD COLOR
BLK(GRN CHAR)/
BLK(RED CHAR)/
BLU (ECHO AREA)
BLU/
BRT
BLU
3 ECHO STRETCH OFF/1/2/3
4 ECHO AVERAGE OFF/1/2/3
5 ECHO COLOR
YEL/GRN/ COLOR*
6 SHIP SPEED LOG/NAV*/MAN
MAN = xx.xKT
(STW/SOG)
7 SET, DRIFT OFF/MAN
SET = xxx.x°
DRIFT = xx.xKT
8 INDEX LINES NO. 2 VRM/MAN
MAN = xx.xx NM
9 BRILLIANCE (1)
0 [FUNCTION 3]
*: R-type only
*1: Fishing mode only (one type of R-type)
[0] key [1] key
[FUNCTIONS 3]
1 [FUNCTIONS 2]
2 [RADAR 1]
3 [FUNCTION KEY 1]
4 [FUNCTION KEY 2]
5 [FUNCTION KEY 3]
6 [FUNCTION KEY 4]
7 RADAR* 1/2
7 INTER SWITCH
8
9 GYRO SETTING EBL = xxx.x°
0 [FUNCTIONS 4]
[2] [RADAR 1]
1 [FUNCTIONS 3]
2 EBL 1 *
REL/TRUE
3 EBL 2 * REL/TRUE
4 VRM 1 *1 NM/km (IMO: nm only)
5 VRM 2 *1 NM/km (IMO: nm only)
6 TRAIL REL/TRUE
7 TRAIL GRAD SGL/MULT
8 [PULSE WD 1]
9 [PULSE WD 2]
0 [RADAR 2]
In RADAR 1 menu, select 8 for pulselength 1 or 9 for pulselength 2. Selection available is as
below for FR-2115/2125/2115-B/2125-B:
0.5 nm range S1/S2 0.75 nm range S1/S2/M1
1.5 nm range S1/S2/M1 3 nm range S2/M1/M2/M3
6 nm range M1/M2/M3/L 12-24 nm range M2/M3/L
