-4.19-
4.12 Plotter Presentation Mode
The plotter presentation mode lets you use factory preset settings or user settings for colors,
brilliance and background of the radar screen; brilliance and color for chart elements and chart
data on/off.
1. Press the [NAV MENU] key.
2. Press the [7] key to select PLOTTER PRESENTATION.
3. Press the [7] key again to select DEFAULT or USER SET.
4. Press the [ENTER] key.
5. Press the [NAV MENU] key to finish.
Below are the settings of DEFAULT.
Item Default Setting
Radar color, brilliance, background
Background color Black
Echo color Yellow
Head line Bright
Plot brilliance M2
Range rings OFF
Brilliance and color of chart elements
Chart M1
Symbols M1
L/L grid M1
Chart information
Danger highlight ON
Coast line ON
Land density ON
Place name OFF
Marks OFF
Own ship plot OFF
Target plot OFF
Contour line OFF
Grid OFF
