Furuno FR-2105-B - Manual (Page 144)

-7.3-
[EPA]
1 VECTOR TIME 30SEC/1/2/3/6/12/15/30MIN
2 COLLISION ALARM OFF/ON
CPA x.xNM
TCPA xx.xMIN
3 MARK SIZE STD/LARGE
4 PLOT NO. OFF/ON
[RADAR MAP]
1 [NAV INFORMATION 1]
2 MAP
OFF/ON
3 MAP NO. MAP xx
MAP LIST
xx xx xx xx xx
xx xx xx xx xx
4 NAV DATA POSN
5 ALIGN +CURSOR DATA
OFF/ON
6 MARK ENTRY MODE CURSOR/OWN SHIP POSN/L/L
7 [ENTER MAP]
8 [MAP DISP SELECT]
9 [MAP ERASE]
[NAV LINE]
1 [NAV INFORMATION 1]
2 NAV LINE
OFF/ON
3 NAV LINE NO. xx - xx - xx - xx
4 NAV WIDTH OFF/ON
x.xxNM
5 WPT NO. OFF/ON
6 WPT xx
(xx) -
• -xx -
(xx) - • -xx -
7 NAV LINE DATA VIDEO PLOTTER/NAVAID/OFF/ALL
8 ARRIVAL ALARM OFF/ON
x.xxNM
9 TURNING LINE OFF/ON/REVISED
[WAYPOINT]
1 [NAV INFORMATION 1]
2 WPT MARK
OFF/ON
3 WPT
WPTxx
WPTxx
WPTxx
WPTxx
WPTxx
4 WPT LINE OFF/ON
5 WPT NO. OFF/ON
6
7
8 ARRIVAL ALARM
OFF/ON
x.xxNM
[ENTER MAP]
1 [RADAR MAP]
2 ENTER MAP
MAP xx
9 ERASE MAP MAP xx
[MAP DISP SELECT]
1 [RADAR MAP]
2 DANGER HIGHLIGHT
OFF/ON
3 COAST LINE OFF/ON
4 MARK OFF/ON
5 NAV LINE OFF/ON
6 PROHIBITED AREAS OFF/ON
7 BUOY OFF/ON
8 CONTOUR LINE OFF/ON
[PLOT MENU] KEY
[NAV INFORMATION 1]
1 [RADAR MAP]
2 SELECT NAVAID
GPS+LC/DEAD
RECKONING
3 OWN SHIP POSN OFF L/L
4 POSN xx
°
xx.xxx N/S
xxx
°
xx.xxx E/S
5 +CURSOR DATA OFF/L/L
6 WPT DATA OFF/REL/TRUE
7 [NAV LINE]
8 [WAYPOINT]
9 WIND DATA
OFF/ON
0 [NAV INFORMATION 2]
[NAV INFORMATION 2]
1 [NAV INFORMATION 1]
2 WIND GRAPH
OFF/ON
3 WIND UNIT m/s/KT
4 CURRENT DATA OFF/ON
5 CURRENT GRAPH OFF/ON
6 DEPTH DATA
OFF/ON
7 DEPTH GRAPH OFF/ON
8 DEPTH SCALE 10/20/50/100/
200/500
9 DEPTH UNIT*1 m/ft
0 [NAV INFORMATION 3]
[NAV INFORMATION 3]
1 [NAV INFORMATION 2]
2 WATER TEMPERATURE* OFF/ON
3 DATE
OFF/UTC/LOCAL
±
xx.xxH
4 USED WPL*
NAV LINE/WP
[MAP ERASE]
1 [RADAR MAP]
2 DANGER HILIGHT
OFF/ALL
3 COASTLINE OFF/ALL
4 MARK OFF/ALL
5 NAVLINE OFF/ALL
6 PROHIBITED AREAS OFF/ALL
7 BUOY OFF/ALL
8 CONTOUR LINE OFF/ALL
[NAV MENU] KEY
(Radar only mode)
[0]
[0]
[1]
[8] [7]
[7]
[8]
[9]
*1: R-type only
