page 2
WARNING: Never expose eyes or skin to UVC light from any source. Looking directly at the UVC light may cause permanent eye damage or blindness.
Never operate the UV-Aire Air Purifying System out of the plenum. Avoid touching the glass portion of the lamp with your hands.
WARNING: Before installing or servicing a humidifier, air filter, heat system, or this unit, etc., always turn
all power OFF and have units unplugged. Electrical shock can cause personal injury or death. Never
expose eyes or skin to direct UV-C light from any source.
WARNING: To prevent water damage or electric shock, do not mount unit under a humidifier.
WARNING: Designed for a closed duct system. Do not mount near a return air opening.
WARNING: This product is designed for indoor installation only (i.e. attics, crawl spaces, basements,
etc.). For use on gas fired, oil fired, electric and split system heat pump forced air systems*. This product
is NOT designed to be mounted outside on gas fired or heat pump packaged units**.
MODEL
MINIMUM
DUCT WIDTH
VOLTS AMPS Hz WATTS
MAx AIR
TEMP ºF
LAMP INTENSITY
AT 1 METER
RECOMMENDED
MAx. Sq. FEET
UV-12C 9" 120 0.5 60 30 190º 37 µW/cm 2 1500
UV-18C 14" 120 0.5 60 30 190º 73 µW/cm 2 2000
UV-28C 22" 120 1.1 60 60 150º 105 µW/cm 2 3000
UV-28 22" 120 1.1 60 60 150º 105 µW/cm 2 3000
UV-12HP 9" 240 0.5 60 30 190º 37 µW/cm 2 1500
UV-18HP 14" 240 0.5 60 30 190º 73 µW/cm 2 2000
UV-28HP 22" 240 1.1 60 60 150º 105 µW/cm 2 3000
UV-12HPC 9" 240 0.5 60 60 190º 37 µW/cm 2 1500
UV-18HPC 14" 240 0.5 60 30 190º 73 µW/cm 2 2000
UV-28HPC 22" 240 1.1 60 30 150º 105 µW/cm 2 3000
The UV-12C,18C, 28C,12HPC,18HPC, and 28HPC units are equipped with a circuit board to monitor the
operation of the UV lamp; it indicates the operation of the lamp through an LED indicator light mounted on the
cover of the unit. The circuit board indicates good operation of the lamp by a continuous GREEN color on the
LED light. After 8,320 hours of lamp operation, the circuit board indicates the elapsed time of lamp operation
by a continuous YELLOW color on the LED light and the internal alarm will beep every 15 minutes. After
9,000 hours of lamp operation, the circuit board indicates the elapsed time of lamp operation by a continuous
RED color on the LED light and the internal alarm will beep every 5 minutes. The board also checks if the UV
lamp is burned out. If the lamp is burned out, the circuit board will indicate this by a continuous RED color on
the LED and the internal alarm will beep every 5 minutes.
INDICATION FOR USE
This product is not sold as a medical device and is not for the purpose of diagnosis of any disease or
condition nor for use in the mitigation, treatment, or prevention of any disease or condition.
GENERAL INFORMATION
There are different size units available, depending on the square footage of your home. See chart below for
determining your home’s needs.
* Split system heat pumps are systems where the air handler and the air conditioning compressor are separate units.
**Packaged units are systems where the air handler and the air conditioning compressor are built together and are
installed outside of the building.
