10Base-T/100Base Tx Port Pinouts
The 10Base-T/100Base Tx port is located on the front of the Ethernet Interface. This port is an 8-
pin RJ-45 “modular phone jack” connector. It is used to connect the Ethernet Interface to a hub,
repeater, switch, or other Ethernet device.
Pin Number
Signal
Description
1
TD+
Transmit Data +
2
TD–
Transmit Data –
3
RD+
Receive Data +
4
NC
No connection
5
NC
No connection
6
RD–
Receive Data –
7
NC
No connection
8
NC
No connection
Note
Pinouts are provided for troubleshooting purposes only. 10Base-T/100BaseTx
cables are readily available from commercial distributors. GE Fanuc
recommends purchasing rather than making 10Base-T/100Base Tx cables.
