5
TABLE OF CONTENTS A
R1502b-0920
Fasteners Shown Actual Size
Note: Tighten and loosen all screws with a Phillips
screwdriver. Do not over-tighten the screws.
5
PARTS
Part Not Shown: Label Sheet
R1502b-0920
7 / 16 " Washer - 8
Super 6 Volt Battery
Steering Bushing
#6 x 1 /
2
" Screw - 2 #6 x 1" Screw - 6
#10 x 1 5 / 8 " Screw - 2
2 Round Bushings
Steering Column
Rear Axle
#10 x 3 / 4 " Screw - 1
#10 Lock Nut - 3
6 Volt Charger
Foam Spacer
3 / 8 " x 16 Lock Nut - 3
Steering Column Cap
2 Assembly Wrenches
#8 x 3 / 4 " Screw - 1
