CardJet 410 Card Printer/Encoder and Persona CardJet C7 Printer User Guide (Rev. 6.1)
2-30
Loading the Ink Cartridges (continued)
Step
Procedure
3
Push the Ink Cartridge firmly, straight down into the Ink Cartridge Cradle.
4
Close the cradle latch. When the latch is fully closed, you will hear a click. Once
both Cartridges are loaded, close the Top Cover. (Note: When loaded properly,
the Ink Cartridge Cradle will return to the home position on the right-hand side of
the Printer and the Ink LED light will turn off indicating that the Ink Cartridges are
installed and ready for printing.) See the
procedure.
