vii
Shaft parts
Name Type Code no. Qty Remarks
Pipe cap SHN-0011-0 661-400-110 1
Jubilee Clip 1X28-41 000-801-857 1
Hex. bolt M10X35 SUS304 000-862-175 2
U-nut M10 SUS304 000-863-930 2
Flat washer M10 SUS304 000-864-131 4
Tank parts
Name Type Code no. Qty Remarks
Hex. bolt M20X80 SUS304 000-801-893 8
Hex. nut M20 SUS304 000-863-116 16
Flat washer M20 SUS304 000-864-136 16
Spring washer M20 SUS304 000-864-270 8
Adhesives
Name Type Code no. Qty Remarks
Kinolastar 855 000-801-328 1 Anti-corrosion
Three Bond 1104 000-854-104 1 Sealant, 200g
Cemedine High Super 6G 000-856-520 1 adhesive
Tank guide
Name Type Code no. Qty Remarks
Tank guide CH-2544 006-557-200 1
Assembly kit for field (Material Box)
Name Type Code no. Qty Remarks
Socket set screw TWB-40 000-804-423 1 4 mm
Shim (0.5) 06-021-4035 100-295-420 2 0.5 mm
Shim (1.0) 06-021-4036 100-295-430 2 1.0 mm
Shim (2.0) 06-021-4037 100-295-440 4 2.0 mm
