10

WARNING

W

AR

NIN

G

Hex. bolt
(M10X30)

Spring washer

Flat washer

Flat
washer

Nut

Trunnion pin

Raise/lower
section

Shaft sleeve

Shaft sleeve and raise/lower drive unit assembly

3. Pass the transducer cable through the main shaft.
