Cables for Installation materials
Code no. Specification (Cable between unit) Type
Monitor unit (or IF)
and Transceiver unit Transceiver unit and Hull unit Crimp-on lug
CP06-01200 000-068-496 06S4080*15m* CP06-01251*
CP06-01201 000-068-497 06S4080*30m* CP06-01251*
CP06-01202 000-068-498
06S4078*5m*
06S4080*50m* CP06-01251*
CP06-01203 000-068-499 06S4080*15m* CP06-01251*
CP06-01204 000-068-500 06S4080*30m* CP06-01251*
CP06-01205 000-068-502
06S4078*10m*
06S4080*50m* CP06-01251*
Control unit cable
Type Code no. Qty Remarks
CP02-06600* 000-012-486 1 MJ-A10SPF0002-0015, for unibody type
CP02-06610* 000-012-480 MJ-A10SPF0002-015, 1.5 m
CP02-06620* 000-012-481
1
MJ-A10SPF0002-050, 5 m
For blackbox type
*: See lists at the back of this manual.
Options
Name Type Code no. Qty Remarks
Remote Controller CH-256-E 000-068-492 1 set
Interface Unit IF-8000 000-068-495 1 set
Motion Sensor MS-100 - 1 set
Speaker SC-05WR 000-136-156 1
Signal Cable S06-9-5 006-556-270 1 Extension cable for speaker
MJ-A6SSPF0012-050 000-134-424 6pin-6pin, 5m
MJ-A6SSPF0012-100 000-133-817 6pin-6pin, 10m
MJ-A6SSPF0011-050 000-132-244 6pin-4pin, 5m
Cable assy.
MJ-A6SSPF0011-100 000-132-336
1
6pin-4pin, 10m
OP06-15-1.5 NEW 006-559-140 For desktop, with 1.5 m
OP06-15-5 NEW 006-559-150
1
For desktop, with 5 m
OP02-83-1.5 001-413-600 1 For flush mount, with 1.5 m cable
Control Unit
Separate Kit
OP02-83-5 001-413-610 1 For flush mount, with 5m cable
OP06-16 006-556-300 1 For unibody type Flush mount kit
OP06-17 006-556-310 1 For separate type display unit
Control unit flush
mount kit OP06-18 006-556-320 1
Rectifier RU-1746B-2 000-030-439 1
06-007-1570-1 600-715-701 1 Steel, 1m
SHJ-0001-1 661-000-011 1 Steel, 1.8m
06-007-1571-1 600-715-711 1 Steel, 3.5m
06-021-4024-0 100-295-470 1 FRP, 1m
06-007-1573-0 600-715-730 1 FRP, 1.8m
Tank
OP10-5 000-069-763 1 Aluminum, 1m
