24G SERIES FLATBOTTOM GAS FRYERS
CHAPTER 2: PARTS LIST
2-11
ITEM PART # COMPONENT
1 106-0882 Probe, Thermostat Assembly, bottom 62.5” with connector (use 106-2607SP for 20” Top)
2 824-1140 Vent, 1824G Wireway (use 824-1139 for 2424G)
3 823-4001 Box, 1824G Wireway (use 823-4000 for 2425G)
4 200-3167 Box, Remote Thermatron Adapter
5 807-1597 Fuse, 3-amp Slow-Blow
6 807-1321 Holder, Panel-Mount Fuse
7 807-3536 Potentiometer, Temperature Control with spade terminals
8 816-0217 Paper, Terminal Block Insulating
9 810-1164 Terminal Block, 1-Piece Screwless
10 826-1359 Screw, 4-40 X ¾-inch Slotted Round Head (Pkg. of 25)
11 826-1366 Nut, 4-40 Keps (Pkg. of 25)
12 810-0045 Bushing. .875-inch
13 807-2469 Bushing, 1-inch
14 810-0678 Bushing, .375-inch
15 807-0125 Bushing, .50-inch
16 200-1671 Cover, Thermostat Entry
17 826-1371 Screw, #8 X .50-inch Slotted Hex Head (Pkg. of 25)
18 826-1680 Clamp, Plastic Wire (Pkg. of 8)
19 807-3559 Thermostat, 435°F High-Limit w/Manual Reset (use 807-3560 for 210°C CE units)
20 807-0800 Transformer, Filter 120V/24V 50/60Hz 50VA
21 106-2058SP Relay Assembly, Boil-Out and Latch (use 106-1648SP for Bracket Switch Assembly)
22 807-3611 Relay, Latch/Filter 24VAC Coil (Left Relay) (use 807-4114 for models after Oct 04)
23 807-3640 Relay, Boil Out 120VAC Coil (Right Relay)
24 807-3613 Spring, Relay Retaining
25 200-1337 Bracket, Oil Return Relay
26 106-1966 Socket Assembly, 24V Oil Return Relay (use 807-3612 for Relay Socket only)
27 816-0220 Insulation, Microswitch
28 807-2103 Microswitch, Straight Lever
29 106-2775 Plate Assembly, Microswitch Adjustment
30 809-0247 Nut, 8-32 Keps
31 200-4719 Plate, Interface Board Mounting
32 809-0853 Screw, 10-32 X 1.5-inch Slotted Pan Head
33 809-0766 Nut, 10-32 Hex Head
34 826-2086 Thermatron Board
35 809-0839 Screw, 8-32 X .75-inch Slotted Pan Head
36 809-0834 Nut, 8-32 Hex Locknut
37 210-3275 Faceplate, 1824G Thermatron Blank (use 210-3168 for 2424G)
38 802-2134 Label, Thermatron Faceplate
39 816-0534 Knob, Thermatron Control
40 210-1985 Faceplate, Single Fryer Thermatron Blank
41 820-0136 Faceplate with Label, Old-Style Single Fryer 5.17” H x 4.04” W
42 820-0135 Faceplate with Label, Old-Style SCF 3.13” H x 6.38” W
43 210-3754 Control Panel, 1824G Two-Switch (use 210-4977 for 2424G)
44 210-2716 Control Panel, 1824G Two-Lamp (use 210-2652 for 2424G)
45 807-3574 Switch, Power ON/OFF Rocker
46 807-3576 Switch, Momentary Reset
47 807-3580 Switch, Boil-Out
48 106-1978 Lamp Assembly, Red 120V 807-3581 lamp only (106-4687 230/250V)(106-4730 24V white)
49 106-4686 Lamp Assembly, Green 120V 807-3582 lamp only (106-4686 230/250V)(106-4729 24V)
50 200-4602 Box, Single Fryer Control
51 210-2689 Plate, Single Fryer Control Panel
52 802-2085 Label, Single Fryer Control Panel
53 200-3901 Lid, Single Fryer Control Box
54 200-3356 Cover, Single Fryer Control Box Access
* 807-3577 Circuit Breaker, 7 amp
* Not illustrated.
