24G SERIES FLATBOTTOM GAS FRYERS
CHAPTER 2: PARTS LIST
2-3
ITEM PART
#
COMPONENT
1 810-2129
Tube,
Burner
2
200-1670
Support, Left or Right Manifold
3
810-2168
Burner Manifold Assembly
4
Orifice
810-2827
2.82mm (#34) Natural Gas
810-2830
1.78mm (#50) Propane (LP) Gas
5 813-0154
Plug,
⅛-inch NPT (Manifold Pressure Tap Plug)
6
813-0174
Union, ¾-inch NPT Pipe
7
813-0300
Nipple, ¾-inch NPT X 4½-inch
8
813-0066
Elbow, 90° X ¾-inch NPT
9
813-0112
Nipple, ¾-inch NPT X 2-inch
10
813-0168
Elbow, 90° X ¾-inch NPT Street
11
Valve,
Gas
807-3555
24V Natural (G20/G25) Honeywell
807-3690
24V Propane (LP) (G31) Honeywell
810-2156
120V Natural (G20/G25) Robertshaw
810-2323
120V Propane (LP) (G31) Robertshaw
*
810-0691
Vent tube
12
813-0763
Bushing, ¾-inch NPT to ½-inch NPT
13
813-0022
Nipple, ½-inch NPT X Close
14
813-0173
Union, ½-inch NPT Pipe
15
813-0165
Elbow, 90° X ½-inch NPT Street
(for single fryers, use 45° 813-0342)
16
813-0265
Nipple, ½-inch NPT X 2½-inch
17
813-0062
Elbow, 90° X ½-inch NPT
18
813-0845
Nipple, ½-inch NPT X 29¾-inch (single fryers, use 24½-inch 813-0788, 813-0729 23”)
Electronic Ignition Components
19
807-3556
Ignitor and Flame Sensor Assembly (does not include flame sensor wire or cable)
*
106-4580
Ignitor Bracket, Flat Style (After Oct 04)
*
210-6184
Ignitor Bracket with bends (used prior to Oct 04.)
* 106-1645SP Flame
Sensor
Wire
20 106-1644SP Ignition
Cable
(includes 807-3742 cable and 807-3484 Rajah connector)
21
807-0918
Module, Ignition (Spark Module) 11 sec. Honeywell
22
826-1389
Screw, ¼-20 X ¾-inch (Pkg. of 10)
23 809-0823 Nut,
¼-20
Nylock
* 807-3551 Transformer,
Electronic
Ignition
Pilot Ignition Components
24
Pilot
Burner
106-0849SP
Non-CE Natural Gas (includes burner, thermocouple, gas line and bracket)
810-2400
Non-CE Propane (LP) Gas #16 (Orifice Only)
812-1286
CE Natural Gas (G20/G25)
25
Thermocouple
807-3550 Non-CE
(use 812-1284 for CE Thermocouple)
*
810-0703
Gas Line, ¼-inch X 17½-inch
*
200-1416
Bracket, Pilot Support
Piezo Ignitor Components (CE Units only)
* 810-1001 Trigger
* 807-3540 Electrode
* 200-1868 Bracket
* 807-3650 Lead,
Trigger to Electrode
*Not illustrated.
