2
FTP-627USL431/631
Part number FTP-627USL431/435 FTP-627USL631/635
Printing method Thermal-line dot method
Dot structure 432 dots/line
Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density
Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch
Effective printing area 54 mm
Number of columns ANK 36 columns/line (maximum 12 x 24 dot font)
Paper width 58 mm
Paper diameter 83 mm
Paper thickness 60 to 100 µ m (some paper in this range may not be used because of
paper characteristics)
Printing Speed Maximum 100mm/sec. (800 dot line/sec.) at 24V, 25 o C
Maximum 150mm/sec. (1200 dot line/sec.) at 24V, 25 o C
Alphanumeric, kana: 159 types
International characters: 195 types
JIS Kanji (Kanji CG loaded board): about 6800 types
12 × 24 dots, (1.5 × 3.0 mm), 36 columns: ANK
24 × 24 dots, (3.0 × 3.0 mm), 18 columns: ANK
8 × 16 dots, (1.0 × 2.0 mm), 54 columns: ANK
16 × 16 dots, (2.0 × 2.0 mm), 27 columns: ANK
UPC-A, UPC-E, JAN (EAN) 13, JAN (EAN) 8, Code 39, 1TF CODABAR
Barcodes CODE128
QR, Maxi , PDF417
Printing mode Page mode, line model
 ParT NUMberS
* Interface board is the FTP-627DSL601R (Serial /USB)
FTP-627DSL603/613-R (USB)
FTP-627DSL605/615-R (Serial)
 SPeCiFiCaTiONS
Specifications Item
Character types
Character, dimensions (W×H), number of
columns
Standard
Extended
2-D
Part Number Power Spool
Printer mechanism /cutter and board FTP-627USL431/631 (USB Interface) 5V / 24V Y
FTP-627USL435/635 (Serial Interface) 5V / 24V Y
FTP-627USL440/640 (USB /Serial) 24V only N
Length
Operation panel cable FTP-627Y203 300mm
Interface cables Serial (RS-232C) FTP-628Y302 500mm
USB (V1.1) FTP-629Y301 1,000mm
Power cables Logic FTP-629Y401 300mm
Head, Motor FTP-629Y601 300mm
USL4xx
USL6xx
