ASSEMBLY STEP
BOLT (I)
CONSOLE MAST
SUPPORT BAR
HARDWARE BAG CONTENTS :
Open HARDWARE BAG .
Align SUPPORT BAR with holes in CONSOLE MASTS.
Insert BOLTS (I) into all 4 holes of the SUPPORT BAR.
NOTE: Look into holes in the right mast before inserting bolts to avoid pinching cables.
Tighten all console bolts (Step 3) and support bar bolts (Step 4) completely.
A.
B.
C.
D.
BOLT (I)
15 mm
Qty: 4
