42" Side Discharge Deck Pulley Assembly
NOTES:
1. Torque to 73 ft. lbs.
2. Torque to 145 ft-lbs.
3. See “42" Deck Belt Routing and Tensioning” on page 7-7 for belt
tensioning.
4. See “Spindle Assembly–601804” on page 6-10 for breakdown.
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 600726 600726 1 BELT, A 114.3" EL (42" DECK)
2 794446 794446 2 CS .625-11X1.500 HX G5
3 046821 046821 2 FW .656X 2.00X.078 ZNYC
4 797449 797449 4 FW .650X1.125X.18 ZNYCG5
5 784504 784504 2 PULLEY, IDLER, 5.00"OD
6 109770 109770 1 IDLER SLIDE W/A
7 781302 781302 1 IDLER SPRING
8 259812 059931 1 CHAIN DECK LIFT SPRING (13 LINKS)
9 784199 784199 4 CS .312-18X1.250 FLT SH
10 601619 601619 2 IDLER SLIDE UHMW RT & LT
11 705954 705954 2 CS .500-13X1.25 HX G5 Z
12 798603 798603 2 FW .515X1.65X.125 HD ZY
13 793778 793778 2 DECK SPINDLE PULLEY
14 045765 045765 2 FW 1.030X 1.500X.134 ZN
15 054502 054502 8 NT .375-16 HX GRD 5 ZNY
16 767954 767954 16 FW .406X .812 X.060 SAE
17 110892 110892 1 PULLEY COVER, LH
18 110891 110891 1 PULLEY COVER, RH
19 601804 601804 2 SPINDLE ASSEMBLY
20 005116 005116 8 CS .375-16X1.375 HX G5
21 793794 793794 2 BLADE,20.50"-L-F-CW
22 782474 782474 2 CW .631 2.250X .187 PNT
23 781872 781872 2 CS .625-11X1.25 HX G5 Z
24 768523 768523 8 FW .343X.687X.051/.080H
25 034280 034280 4 CS .312-18X .750 HX G5
26 058776 058776 4 NT .312-18 HXZY NL
