Hustler Turf 929125 - Manual (Page 20)

3-10 110907 01/09
Steering Assembly
NOTES:
1. Service parts for Damper:
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 600221 600221 2 DAMPER, STEERING
2 023655 023655 4 NT .312-24 HXZY NL
3 768523 768523 12 FW .343X.687X.051/.080H
4 034272 034272 4 NT .312-18 HX G5 ZNYC
5 600981 600981 2 PUMP ROD ASSEMBLY
6 034280 034280 1 CS .312-18X .750 HX G5
7 110014 110014 1 PIVOT TUBE ASSEMBLY
8 705178 N/A 2 CS .375-16X1.750 HX G5
9 767954 767954 4 FW .406X .812 X.060 SAE
10 086660 N/A 2 NT .375-16 HXZY NL
11 781922 781922 4 BALL STUD, DAMPER (FS)
12 029876 029876 2 LW .312 INT-EXT TOOTH Z
PART
NUMBER
DESCRIPTION
601425 CONNECTOR BODY
601426 CAP LOCK
