3-12 110907 01/09
Park Brake Assembly
NOTES:
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 110001 110001 1 BRAKE ACTUATOR LH
110000 110000 1 BRAKE ACUTATOR RH
2 765339 765339 4 BUSHING,IGUS#0608 (FS)
3 781211 781211 2 SWITCH, PUSH BUTTON(FS)
4 063198 063198 4 CS 10-24X .750 HXFLK ZN
5 601822 601822 2 NUT PLATE, .420 CENTERS
6 725796 725796 2 CS .375-16X4.00 HX G8 Z
7 767954 767954 4 FW .406X .812 X.060 SAE
8 110009 110009 2 BRAKE ACTUATOR ROD
9 768523 768523 8 FW .343X.687X.051/.080H
10 048553 048553 2 CP .062DX1.000 LG HML Z
11 023655 023655 4 NT .312-24 HXZY NL
12 068551 068551 4 NT .250-20 HXZY NL
13 086660 086660 2 NT .375-16 HXZY NL
14 768515 768515 4 FW .281X.625X.051/.080H
15 601131 601131 2 SPRING, BRAKE ARM RET.
