Hustler Turf 929125 - Manual (Page 17)

110907 01/09 3-7
Hydro Transmission Installation
NOTES:
1. Torque to 17 ft-lbs.
2. Torque to 100 ft-lbs.
3. Service parts available for the transaxles:
4. Push all the slack in the transmission to rear and then tighten bolts.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 043067 043067 4 CS .312-18X3.00 HX G5 Z
2 710087 710087 4 CS .312-18X2.500 HX G5
3 768523 768523 16 FW .343X.687X.051/.080H
4 769133 769133 1 BELT, A 67.24" EL
5 602026 602026 2 BEARING DISC
6 111079 111079 1 PUMP IDLER, FORMED
7 036384 036384 1 SPRING 1/4 COIL PL 1.23
8 016972 016972 1 NT .625-11 HX G5 ZNYC
9 784827 784827 1 PULLEY, IDLER, 4.00"OD,
10 028118 028118 3 FW .625X1.00X.134 ZNYC
11 601983 601983 1 CS .625-11 X 2.25 HXG5ZY
12 601390 601390 1 EZT, 19.2 LEFT TRANS
13 110042 110042 1 HYDROSTAT CROSS BRACE
14 056036 056036 4 CS .375-16X2.250 HX G5
15 767954 767954 8 FW .406X .812 X.060 SAE
16 054502 054502 4 NT .375-16 HX GRD 5 ZNY
17 034272 034272 8 NT .312-18 HX G5 ZNYC
18 601391 601391 1 EZT, 19.2 RIGHT TRANS
19 793174 793174 2 TOWLINK ROD
20 048553 048553 2 CP .062DX1.000 LG HML Z
21 601018 N/A 2 OVERFLOW HOSE
22 017616 017616 1 CS .500-13X1.750 HX G5
23 602025 602025 1 BUSHING, IGUS .500 I.D.
24 781567 781567 1 NT .500-13 HX G8 ZY NL
25 601398 601398 1 SPACER, SPORT IDLER
PART
NUMBER
DESCRIPTION
PART
NUMBER
DESCRIPTION
788877 AXEL NUT 791723F FW .530 X 1.63 X .06 SLO
601206 EZT PULLEY KIT 788232 HUB ASSEMBLY
601207 PULLEY, 4.5", FST ZT2800 798363 PARKING BRAKE GEAR
795039 LEFT EZ VENT TUBE ASSY 795062 RIGHT EZT VENT HOSE
