AL010 Lift Operation
"PLATFORM KEEPER"
Insert Key and switch to "ON" position
Press down on Toggle switch momentarily. Once platform has been lowered at least an
inch, unfold the platform. Continue lowering
to the ground.
Drive scooter onto platform as shown. Raise hold down arm.
Raise platform until hold down foot depresses
scooter's deck or until lift's motor ratchets.
1 2
3 4
5
To remove the scooter and prepare the lift
for unloaded travel, follow above steps in
reverse order and reverse the direction
of the arrows.
. Verify that the
platform keeper has
engaged the platform's
pin.
Lift should be raised
with the platform folded
and until the lift's motor
ratchets
