AL050 Lift Operation
Raise platform with toggle switch, until
motor's ratchet sound is heard. 5
1 Insert Key and switch to "ON" position
Press down on Toggle switch momentarily.
Drive chair onto platform as shown. 3
To remove the chair and prepare the lift
for unloaded travel, follow above steps in
reverse order and reverse the direction
of the arrows.
. Verify that the
platform keeper has
engaged the platform's
Lift should be raised
with the platform folded
and until the lift's motor
ratchets
Once platform has been lowered at least an
inch, unfold the platform. Continue lowering
to the ground. 2
"PLATFORM KEEPER"
NOTE: The Platform will not be
allowed to unfold until the platform
has been lowered at least an inch.
PULL to
TIGHTEN
PUSH to
RELEASE
Strap the chair down using the 4 straps
located on each corner of the platform. 4
pin.
