Heat & Glo LifeStyle Collection • Twilight-II • 2087-900 Rev. G • 12/05 22
E. Positioning the Logs
Log Set Assembly: LOGS-TWI
1
2
2005-937D
CAUTION: Logs are fragile! Carefully remove the
logs from the packaging. Remove the metal supports
which held the log box in place during shipping.
STEP 2. LOG #1 (SRV2005-701): Use the indents on the bottom side of the log to position the large end of the
log onto the grate tine as shown. Position the thin end of log #1 one inch from port pattern as shown.
STEP 3. LOG #2 (SRV2005-700): Position log #2 on the left grate bar and the pilot assembly. Use the cut out
notches on the log to position it as shown.
STEP 1. Before positioning the logs, refer to the
installation manual for electric ember set-up and ember
placement.
1
2
4
5
6
7
3
Indents
Pilot
Assembly
Cutout
Grate Bar Cutout
1-inch
