Model 690
HENNY PENNY
8 HEAD GAS PRESSURE FRYER
SPECIFICATIONS
Height 61" (155 cm)
Width 24" (61 cm)
Depth 41¾" (106 cm)
Floor Space Approximately 7 sq. ft. (0.65 sq. m.)
Pot Capacity 8 head of chicken (32 lbs.) (14.5 kg)
130 lbs. shortening (59 kg)
Electrical 120 VAC, 1 Phase, 50/60 Hz, 10 Amp, 3 Wire Service
230 VAC, 1 Phase, 50 Hz, 3 Wire Service
Heating Propane or Natural Gas; 100,000 btu/hr (105.51 MJ/hr)
Pressure 12 psi operating pressure (827 mbar)
14.5 psi safety relief pressure (999 mbar)
Shipping Weight Approximately 935 lbs. (424 kg)
A data plate, located on the back shroud behind the lid, gives the information of the type of
fryer, serial number, warranty date, and other information pertaining to fryer. Also, the serial
number is stamped on the outside of the frypot. See figure below.
