Impact VC-500WLN 500Ws Monolight - Manual (Page 26)

26
Specifications
Power Output 500 Ws
Guide Number 78
Output Control Range Full to 1/32 in 1/10 increments
Recycle Time (110~120 V 60 Hz) 0.2 to 1.5 sec.
Flash Duration 1/800 to 1/1200 sec.
Flash Ready Indicator Visible or audible confirmation
Power Range 6 stops
Modeling Lamp E26/27, 250 W Max
SSC (soft-start circuitry)
Modeling Lamp Control Proportional, Independent, Off
Triggering Method 16-channel wireless transmitter (included
with kits only), direct connect
6.35 mm phono plug to PC cord (optional
accessory), optical slave with preflash
settings.
Effective Wireless Distance Range 328 ft. (100 m)
Battery Replacement for
Transmitter
CR2032 3 V
Color Temperature 5600 K (±100 K)
Flash Tube User-replaceable plug-in tube
Trigger Voltage DC 5 V
Sync Cable Input 1/4 " (6.35 mm)
