Remote Connect Web Interface

The Remote Connect Web Interface allows remote access to your AllSync IQ Master via a web browser. This includes Event and Circuit

programming, manual circuit activation, time/date settings and other system configurations.
This feature is available to all AllSync IQ Masters with the Ethernet option.
Note: Java SE Runtime Environment (JRE) 7 Update 7 will need to be installed to run the Events Applet.
–This can also be downloaded at http://www.java.com/en/
–Ensure that you have the most current web browser (ie. Firefox, Internet Explorer, Chrome)

To access Remote Connect:

1. Ensure that the AllSync IQ Master installation has been performed (page 5) and that the Ethernet option has been

configured (pages 6-10)

2. Open a web browser. Enter the IP address for your system controller or asiq plus last six digits of MAC address (if DHCP is

Enabled) (#3 on page 10) as http://xxx.xxx.xxx.xxx in the web browser’s Address field (Figure 1) or http://asiqxxxxxx/. Press the

Enter key.

Note: If using DHCP Host Name, the network or computer connected to the AllSync IQ Master for configuration must be on

the same subnet for Host Name to work properly.

Figure 1

3. A User Login window, (Figure 2) will appear. There are two available user names,

uclock and sclock, which represent the user

and service access levels. The user security level allows access to everything but the Configuration Tab.

User Level Access:

Enter

uclock in lowercase letters in the User Name field and uclock in the Password field. This is a user login which will allow

access to time/date and event menus.

Service Level Access:

Enter

sclock in lowercase letters in the User Name field and sclock in the Password field. This is a service login which will

allow access to all menus.

**Passwords may be changed in the Configuration Tab.

Then, click the Login button.

Figure 2

4. The Remote Connect utility will appear with the General tab selected. The tabs displayed may differ depending on the

configuration of the unit.

Figure 3

For more details on the features of Remote Connect, click on the Support link in the upper right-hand corner of the utility (Figure 3).
