DAY/NIGHT: It is to set camera day/night switch mode. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.



THRESHOLD: The speed dome can switch the day/night mode when it reached the threshold you set
here.
 

DAY/NIGHT MODE: It is to set day/night switch mode. Click left/right button to set.



SAVE: This button is for DAY TIME and NIGHT TIME setup. After you set the day time (or night
time), you need to move the cursor here and then click confirm button to save current time setup.
For other setups, you do not need to use this button.



BACK: Go back to previous menu.



EXIT: Log out system menu.

3.4.3.5 Focus Setting
FOCUS MODE ： AUTO
FOCUS LIMIT ：10CM
AF SENSITIVITY ： NORMAL
IR CORRECTION ： ATUO
BACK EXIT
Figure 3-16 Focus setting

FOCUS MODE: It is to set the camera focus mode. It includes several modes such as auto, manual,
semiautomatic. Please use the left/right button on the keyboard or in the speed dome terminal menu
to set.



FOCUS LIMIT: It is to set the camera focus limit. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.



AF SENSITIVITY: It is to set the camera focus sensitivity. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.



IR CORRECTION: It is to set the camera IR light focus correction. Please use the left/right button on
the keyboard or in the speed dome terminal menu to set.
 

BACK: Go back to previous menu.



EXIT: Log out system menu.

3.4.3.6 Image Adjust
Move the cursor to IMAGE ADJUST and then click confirm button to go to the submenu to set.
HUE ：50
BRIGHTNESS ：50
SATURATION ：50
CHROMA SUPPRESS ：01
GAMMA ：01
CONTRAST ：50
STYLE ：STANDARD
BACK EXIT
Figure 3-17 Image Adjust

HUE : It is to set picture hue. Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.

BRIGHTNESS: It is to set picture brightness. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.



SATURATION: It is to set picture saturation. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.



CHROMA SUPPRESS: It is to set picture color control. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.

