3.4.1.2 Address Information
ADDR TYPE ：HARD
ADDR-HARD ：1
ADDR-SOFT ：0
BACK EXIT
Figure 3-5 Address information
Move the cursor to SITE INFORMATION and then click confirm button.

ADDR TYPE: There are two options: soft and hard. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.
 

ADDR-HARD: It is an address you set in the dial switch. You can not modify it through software.



ADDR-SOFT: You can set address via software. It is to say, you can use menu to modify dome address.



BACK: Go back to the previous menu.



EXIT: Log out system menu.


3.4.2 Display Setting
PRESET TITLE ：ON
AZIMUTH DISP ：ON
POSITION ：OFF
INSIDE TEMP ：℃
BACK EXIT
Figure 3-6 Display setting
Move the cursor to DISPLAY SETUP and then click confirm button, you can go to the third submenu.
Please use the left/right button on the keyboard or in the speed dome terminal menu to set. After
completed setup, please click save button to save current setup.

PRESET: Display dome preset title or not. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set. You can go to Function Setup->Preset section to set
corresponding preset value and preset title.



AZIMUTH DISP: Display dome current coordinates or not. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.



POSITION: Display the angel between the benchmark and then current location. Please use the
left/right button on the keyboard or in the speed dome terminal menu to set.



INSIDE TEMPERATURE: Display dome internal temperature or not. There are three options:
℃
/F/Off. Please use the left/right button on the keyboard or in the speed dome terminal menu to set.



BACK: Go back to the previous menu.



EXIT: Log out system menu.


3.4.3 Camera Setting
WB SETTING
EXPOSURE SETTING
DAY/NIGHT SETTING
FOCUS SETTING
IMAGE ADJUST
：8 ZOOM SPEED
NEXT PAGE
BACK EXIT
Figure 3-7 Camera setting
APERTURE ：9
APERTURE RESTRAIN ：10
DIGITAL ZOOM ：OFF
PICTUER FLIP ：OFF
LENS INITIALIZATION
：720P/25 PICTURE MODE
NEXT PAGE
BACK EXIT
Figure 3-8 Next page
