Figure 3-10 White balance
Move the cursor to WHITE BALANCE MODE and then click confirm button, you can go to the submenu.

WHITE BALANCE MODE: Set white balance adjustment mode. There are several modes such as
auto, ATW, indoor, outdoor, and manual and etc. Please use the left/right button on the keyboard
or in the speed dome terminal menu to set.



R GAIN: Before you set R GAIN option, please note the mode is manual. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.



B GAIN: Before you set B GAIN option, please note the mode is manual. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.
 

BACK: Go back to previous menu.



EXIT: Log out system menu.

3.4.3.2 Exposure Setting
AE MODE ：AUTO
GAIN SETTING ：2
SHUTTER ：1/50
IRIS SETTING ：4
EXPOSURE COMP ：8
SLOW SHUTTER ：ON
NEXT PAGE
BACK EXIT
AGC GAIN LIMIT ：2
SLOW SHUTTER LIMIT ：1/25
NOISE REDUCTION ：3
3D NOISE REDUCTION ：OFF
BLC ：OFF
WDR SETTING
NEXT PAGE
BACK EXIT
Figure 3-11 Exposure setting Figure 3-12 Next page
HIGH LIGHT REUDCE ：OFF
AE RECOVERY ：15M
BACK EXIT
Figure 3-13 Next page

AE MODE: Here you can set the camera exposure mode. It includes: auto/manual/AV (iris
priority)/TV (shutter priority). Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.

o Auto: The gain, iris, shutter are in auto mode.
o Manual: You need to set the gain setting, shutter, and iris setting manually.
o Iris Priorit y (AV): I t is for you t o s et t he iris manuall y. G ain and s hut ter ar e in aut o mode.
o Shutter Priority (TV): It is for you to set the shutter manually, Gain and iris are in auto
mode.

GAIN SETTING: It is to set camera gain. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.



SHUTTER: It is to set camera shutter. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.



IRIS SETTING: It is to set camera iris. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.



EXPOSURE COMP: It is to set camera exposure compensation. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.



SLOW SHUTTER: In lower illumination environment, you can lower the cameras auto exposure
time to capture the image and enhance the definition. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.



NEXT PAGE: It includes: AGC GAIN LIMIT, SLOW SHUTTER LIMIT, NOISE REDUCTION,
3D NOISE REDUCTION, BLC, HIGH LIGHT REDUCE, WDR, AE RECOVERY, BACK, and
EXIT. Move the cursor to the item and then click the left/right button to set.

