30
WAT0001
ITEM NO. PART NUMBER DESCRIPTION default/QTY.
1 WPT0058 WT Bottom Plate Front 1
2 UF7009 SS BHCS M4-0.7 x 8 4
3 WPT0063 WT Upper Guide Plate 1
4 WPT0067 WT Brush Pot Locator 1
5 UF7011 SS BHCS M5-0.8 X 12MM 6
6 WST0002 WT Frame Left Side SA 1
7 UF7008 SS BHCS M4-07 X 6MM 4
8 WPT0042 WT Washer 1
9 WPT0072 SS E-Ret'g Ring External 16mm 1
10 WPT0057 WT Bottle Locator 2
11 UF7012 SS FHCS M5-0.8 x 8 mm 4
12 UF3276 SS BHCS M5 X 0.8 X 6MM 6
13 UF 7021 SS LW 5MM 2
14 WPT0056 WT Hinge 2
15 WPT0060 WT Top Cover 1
16 WPT0059 WT Bottom Plate Rear 1
17 WST0003 WT Bottle SA 1
18 UF7019 SS E Ret'g ring external 10mm 3
19 WST0004 WT Self Centering SA 1
20 UF6389 NYLON F.W. 10.5 x 16 x 0.5 mm 4
21 WST0014 WT Knife Arm c/w Cutter Blade 1
22 WPT0062 WT Feed Roller Pivot Shaft 1
23 WPT0068 WT Tape Roll Roller 1
24 WPT0061 WT Feed Roller 1
25 WST0001 WT Frame Right Side SA 1
26 WST0012 WT Drive Roll Pivot SA 1
27 UF3638 SS HNR M6-1.0 2
28 UF7002 SS M6-1 X 50MM SHCS 1
29 UF7020 SS E Ret'g Ring External 6mm 2
30 WST0010 WT Drive Roll Pivot SA 1
31 WST0008 WT Cover SA 1
32 WST0005 WT Handle SA 1
33 WPT0070 WT Plastic Plug 1
34 UF3183 SS SHCS M6-1 X 12mm 1
35 UF6341 SS LW 6MM 1
36 WPT0069 WT Washer 1
37 WPT0071 WT Ext'n Spring c/w Hook 1
38 UF3180 SS M6-1 X 25MM SHCS 1
39 WPT0064 WT Stopper 1
40 UF7001 SS M6-1 X 40MM SHCS 1
41 WPT0065 WT Spacer 1
42 WST0006 WT One Way Gear SA 1
43 WST0011 WT Drive Roll SA 1
44 WPT0066 WT Double Gear 1
45 WST0007 WT Brush Pot SA 1
46 WST0013 WT Tape Guide SA 1
47 WST0009 WT Pinch Roller SA 1
