TWA 1000-M (U9701) UDM 9701
13
S
ET
-U
P
P
ROCEDURES
Receiving and Handling
All contents must be verified upon reception. The following items are included with each tape head.
TWA 1000-M Manual Taper U9701
Operators Manual
UDM 9701
Note: After unpacking the taper, look for any damage that may have occurred during
shipping. Should the Taper be damaged, file a claim with the transport company and
notify your Intertape representative.
Selecting The Handle Position
Figure 7-1
The machine ships with the pull handle mounted
toward the inside of the machine
The location of the handle can be reversed should
an outside location be preferred
1. Remove the lock nut with a 17mm wrench
and a 5mm allen key
2. Reverse the handle to the position shown in
Figure 7-2
3. Reinstall the locking nut
Figure 7-2
