TWA 1000-M (U9701) UDM 9701
17
S
ET
-U
P
P
ROCEDURES
Removing The Moistening Brush
Figure 7-9
1. Lift off the right side of the pressure plate
assembly.
2. Slide the pressure plate from the left side of
the brush pot
3. Pull the brush straight out from the brush
pot
4. Notice the brush angle. When replacing
the brush, insert at the same angle.
Figure 7-10
Moistening
Brush
Pressure
Plate
