MultiMount™ MM-024
Speaker Wall and Ceiling Mount Installation Instructions
Thank you for selecting the MultiMount™ MM-024 speaker Mounting kit. This
mounting kit contains one speaker mount that positions speakers weighing up
to 60 lbs/27 kg. from most wall and ceiling structures. The MultiMount-022
simplifies and speeds up wall and ceiling speaker installations while achieving
a very versatile range of speaker positioning.
Warning:
Mounting and/or rigging loudspeakers requires experienced professionals.
Improperly installed loudspeakers can result in property damage,
personal injury, death and/or liability to the installing contractor.
To assure a trouble free installation, read through and follow these
instructions carefully before beginning. If you have doubts about the integrity
of the structure you are mounting to or you are not sure about the proper
hardware to use, consult a structural and/or hardware specialist.
Be sure that all of the following items are included in this kit before
proceeding.
Item# Qty. Description Item# Qty. Description
1. 1 pc. Mounting plate 5. 2 pcs. 3/4" ext. star lock washer
2. 1 pc. Speaker adapter plate 6. 1 pc. 5/16-18 x 1” socket screw
3. 1 pc. Support arm Assy. 7. 1 pc. 1/4” dia. x 3/4” stop pin
4. 2 pcs. 3/4"-16 x 1.00" Hex bolt 8. 1 pc. 5/16" flat washer
Note to installing contractor:
Due to the wide variety of wall structures, materials and mounting methods, these instructions
assume that the installing contractor will exercise proper judgment in selecting the mounting area
and hardware.
As a guide, the installation, when complete should be capable of supporting 5 to 10 times the
actual applied load. Also, use a back up safety system such as a safety cable.
Step 1
(A) Mounting to a wall
Attach the mounting plate to the wall with the open center slot towards the ceiling using the
appropriate hardware for the application (Figure 1). If in doubt, consult a local hardware
specialist. Push the stop pin into the lower center hole of the wall plate (Figure 1).
(B) Mounting to a ceiling
Predetermine the desired direction of the speaker. Attach the mounting plate
to the ceiling structure with the open center slot towards the speaker using
the appropriate hardware for the application. Push the stop pin into the lower
center hole of the wall plate.
Step 2.
Attach the speaker adapter plate to the appropriate mounting holes of the
speaker using the manufacturer’s suggested screws and washers. Tighten
these fasteners permanently. If threaded inserts are not included on the
speaker, consult the speaker manufacturer for proper mounting procedures.
Figure 1
