ASSEMBLY
ASSEMBLY
LOCATION
PARTS BAG CONTENTS SHOWN FULL SIZE
BATTERY
(2) Wing Nut 1/4-20
BATTERY
TERMINALS
(2) Hex Bolt 1/4-20x3/4
(2) Lock Washer 1/4
O
{2) Washer 9/32 x 5/8 x 16 Ga
(2) Hex Nut 1/4-20
SEAT
(1) Adjustment Boll
(1) Washer 17/32 x
1-3/16 x 12 Ga
(1) Shoulder Bolt 5/16-18
STEERING
BUSHING
(2) Sheet Metal Screw 10-16 x 1/2 ABTBS
STEERING
WHEEL
