Craftsman 917.276310 - Manual (Page 31)

TRACTOR - - MODEL NUMBER 917.276310
SCHEMATIC
02832-193394 \ 193395 EHP RCS LT WITH BYPASS SWITCH / ELECTRIC CLUTCH
.BATTERY
IGNITION SWITCH
REVERSE SW ITCH
SHORTING CONNECTOR
rh BLACK I ^ r-i I NOT IN REVERSE
^ TcJ LJ I BLACK
ELECTRIC C LUTCH
j-Cy—
BLACK y ■AiHIIÉ -O
®- -^1
IGMITION _Q SPARKPLUeS
UNIT
( 2 PLUGS
./INC" ■ ■ ONTWINCYL. ENGINES)
EUEt SHijr-OFF
SOLENOID
c HOUR
METER
^ FUEL
W LINE
I.-
{OPTiONAL)
(IF SO EQUIPPED)
CHAIÍG3NG SYSTEM OUTPUT ni^nwwPrTP
16 AMP DC ® 3600 ñPM (HLCULAiüfl
REGULATOR
I ALTERNATOR
POSITION CIRCUIT “MAKE”
OFF M+G+A1
t^UN/OVeMRlDE B+A1
RUN 0+.A1 L+A2
START S-t- S + A1
NOTE
YOUR TRACTOR IS
EOUIPPED WITH A SPECIAL
ALTERNATOR SYSTEM.
THE LIGHTS ARE NOT
CONNECTED TO THE
BATTERY, BUT HAVE THEIR
OWN ELECTRICAL SOURCE.
BECAUSE OF THIS, THE
BRIGHTNESS OF THE LIGHTS
WILL CHANGE WITH ENGINE
SPEED. AT IDLE THE LIGHTS
WILL DIM. AS THE ENGINE IS
SPEEDED UP, THE LIGHTS
WILL BECOME THEIR BRIGHTEST,
HEADLIGHTS
NON-REMOVABLE
CONNECTIONS
REMOVABLE
CONNECTIONS
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED CLIPS
WERE REMOVED FOR SERVICING OF
UNIT, THEY SHOULD BE REPLACED
TO PROPERLY SECURE YOUR WIRING.
31
