W
HEATHEART
- X13 S
ERIES
A
UGERS
6. O
PERATION
X1374, X1384, X1394
6.3. O
PERATING
P
ROCEDURES
30787 R1
95
Figure 6.5 Forward and Reverse PTO Positions (1000 RPM PTO
Reverser)
Before Operating in the Normal Forward Mode:
1. The stub spline on the PTO driveline must be inserted into the Forward spline
coupler (see Figure 6.4 and Figure 6.5) and securely locked into place.
2. Make certain the clean out cover is secured into place on the boot before
operating.
3. The PTO drive control on the tractor must be in the off position before starting
tractor and the PTO hazard area is clear of all bystanders.
Note:
All safety shields must be in place before operating.
Forward
Position
Reverse
Position
Reverse
Position
Forward
Position
