W HEATHEART - X13 S ERIES A UGERS 6. O PERATION
X1374, X1384, X1394 6.2. O PERATOR C ONTROLS
30787 R1 89
6.2.1. PTO D
RIVE
O
PERATION
Correct operation of the auger requires pre-inspection of the drive system,
operator knowledge on how to shut down the system, and a general monitoring
of the system during operation.
G ENERAL I NFORMATION
Before starting the auger, ensure that:
• The PTO driveline is securely attached to the auger shaft and to the tractor.
• The PTO driveline rotating shield is in place and in good working order.
• The PTO does not exceed the maximum operating angle of 15°.
• All safety shields are in place and secure on both the tractor and the auger.
• The PTO drive on the tractor is in the off position before starting the tractor.
• The auger-to-tractor PTO hookup distances are set as specified in the decal
on the PTO shield of the auger.
• Everyone is clear of the PTO hazard area.
Note: If shear bolt in the PTO driveline fails, shut down and lock out the tractor to
replace the bolt. Use a 5/16” x 1” GR 8 bolt. Ensure the shear point is through the
shank of the bolt, not the threads.
L OCKOUT
1. Shut down the tractor and remove the ignition key.
2. If step 1 is not possible, remove the PTO driveline from the tractor.
6.2.2. H
YDRAULICS
O
PERATION
X13 series grain augers are equipped with a standard 3/8” Pioneer Coupler used
to connect the auger hydraulic system(s) to the tractor.
Before using the hydraulics, ensure that:
• The quick connect couplers on both the auger and the tractor are clean and
free of dirt. Wipe the couplers with a clean, dry cloth.
• The hydraulic hoses are properly connected and secured; are free of leaks,
wear, and binding; and are routed away from moving parts.
• Hydraulic pressure has been relieved prior to disconnecting.
NOTICE
When positioning the auger, the PTO driveline must be
disconnected from the tractor and placed in the transport
saddle to prevent damage to auger and PTO driveline.
