3. A SSEMBLY W HEATHEART - X13 S ERIES A UGERS
3.16. I NSTALL L OW P ROFILE I NTAKE H OPPER X1374, X1384, X1394
68 30787 R1
Figure 3.35 Connecting the Wheels, Inspection Hatch Bar, and Hopper

Cable Attach Bracket
Figure 3.36 Connecting the Spout Head to the Boot
CABLE ATTACH BRACKET
7/16” X 1-1/4” BOLTS
AND 7/16” LOCKNUTS
INSPECTION HATCH BAR
AND HAIRCLIPS
WHEEL, WHEEL PIN, AND
HAIRCLIP
SPOUT HEAD SPACER
SPOUT HEAD RETAINER
5/16” X 3/4” GR2 BOLT
