Rev 1.0/6-13 2 CB1: #35168
SPECIFICATIONS
Model Number: CB1
Description: In combination with a P2 vacuum lifter, this equipment allows loads to be positioned
under overhangs by extending the lifter away from the lifting slings or rigging, and it
allows the lifter to tilt in a "reverse angle", when needed.
Horizontal Reach: Minimum = 58" [1472 mm]
Maximum = 64" [1628 mm]
Overall Length: Fully contracted = 159½" [4050 mm]
Fully extended = 219½" [5574 mm]
Weight: 470 lbs [214 kg], not including user-supplied ballast material or P2 Channel Lifter
Note: Make sure to add this weight to the lifter weight when you are selecting
appropriate hoisting equipment (see lifter's instruction manual).
WARNINGS
Powr-Grip is pleased to offer the most reliable handling products available.
Despite the high degree of security provided by the Counter-Balancer, certain
precautions must be observed to protect the operator and others.
Never use a Counter-Balancer that is damaged, malfunctioning, or missing parts.
Always read and follow all directions for loading and unloading the Counter-Balancer, as well as
maintaining stability of the Counter-Balancer and load (see ASSEMBLY and OPERATION).
Never allow people to ride on the Counter-Balancer or the load being lifted.
Never lift a load higher than necessary or leave suspended loads unattended.
Never lift a load over people.
Always keep other personnel far enough away from the Counter-Balancer to avoid injury in the
event of an unexpected load release.
Always remember that modifications to the Counter-Balancer may compromise its safety.
Wood's Powr-Grip cannot be responsible for the safety of a Counter-Balancer that has been
modified by the customer. For consultation, contact Wood's Powr-Grip.
