Note: Depending on the position of pad mounts, the pad frame may extend beyond the edges of
smaller loads. When moving such loads, be careful to avoid any obstacles to the pad frame, as
well as to the load.
MAINTENANCE
When performing inspections and tests as directed in the lifter's instruction manual, be sure to
include all parts of each Pad Frame T-Arm Assembly whenever applicable. When necessary,
replace the sealing ring inserts for vacuum pads as directed below.
T
O
R
EPLACE
S
EALING
R
ING
I
NSERT IN
V
ACUUM
P
AD
1) Remove the old sealing ring insert: Hold the vacuum pad firmly and pull the ring insert out
from the mounting groove. Discard any damaged ring insert.
2) Install a new sealing ring insert (see REPLACEMENT PARTS LIST): Push the ring insert into
the mounting groove so that the insert's base (flat side) fits flush against the bottom of the
groove. Begin by placing the inside edge of the ring insert against the inside edge of the
mounting groove. Then push gently and firmly on the outside edge of the ring insert until it
seats completely into the mounting groove. Work your way around the entire ring insert,
repeating this process until the entire ring is seated in the mounting groove.
3) Make sure that the sealing ring is secure and fully inserted into the mounting groove around
the entire perimeter of the vacuum pad.
Note: If the ring insert ever comes partially or entirely out of the mounting groove, inspect the
ring insert for damage and reinstall an undamaged ring insert as directed.
REPLACEMENT PARTS LIST
Stock No. Description Qty.
97467 MRT4-DC Quick Connector Fittings Kit for T-Arm Assemblies 1
65441 Vacuum Hose - 1/4" [6.3 mm] ID x 48" [122 cm] Length - Coiled 4
49724TT Sealing Ring Insert - Model VIFS10T (for VPFS10T pads) 4
49723BT Sealing Ring Insert - Model VIFS625 (for VPFS625 pads) 4
49672T Vacuum Pad - Model VPFS10T / 10" [25 cm] Diameter - w/Replaceable Sealing Ring 4
49122 End Plug - 2" x 2" x 1/4" [50.8 mm x 50.8 mm x 6.4 mm] Tubing Size 4
16057 Quick Connector - 1/8 FNPS - Male End 4
16056 Quick Connector - 1/8 FNPS - Female End 4
13530 Cotterless Hitch Pin - 1/2" x 3 1/2" [13 mm x 89 mm] 6
SERVICE ONLY WITH IDENTICAL REPLACEMENT PARTS
SUPPLIED BY OR APPROVED BY WOOD'S POWR-GRIP CO., INC.
