SPECIFICATIONS
Option Model Number: CF13CEO
Description: When installed, Pad Frame T-Arm Assemblies enable a vacuum lifter to handle
cladding and textured materials with various profiles and dimensions.
Available Vacuum Pads:
VPFS625: Four with nominal dimensions of 6" x 25" [15 cm x 64 cm], spring-mounted (½" [12
mm] travel) with #60 filter screen and replaceable sealing rings
VPFS10T: Four 10" [25 cm] nominal diameter, standard rubber, spring-mounted (¼" [7 mm]
travel) with #60 filter screen and replaceable sealing rings
Compatible Lifter Models:
MRT4-DC
MRTA6-DC
MRTALP6-DC
MRTA8-DC
Adjusted Pad Spread with VPFS625 Pads:
Maximum:
36¼" x 68¾"
36¼" x 87"
36¼" x 92"
36¼" x 113½"
[92 cm x 174 cm]
[92 cm x 221 cm]
[92 cm x 234 cm]
[92 cm x 289 cm]
Minimum:
19¼" x 68¾"
14¾" x 87"
18¼" x 92"
20½" x 113½"
[49 cm x 174 cm]
[41 cm x 221 cm]
[46 cm x 234 cm]
[52 cm x 289 cm]
Adjusted Pad Spread with VPFS10T Pads:
Maximum:
45¾" x 55"
45¾" x 73¼"
45¾" x 78¾"
45¾" x 99¾"
[116 cm x 140 cm] [116 cm x 186 cm] [116 cm x 200 cm] [116 cm x 253 cm]
Minimum:
25¾" x 55"
25¾" x 73¼"
25¾" x 78¾"
25¾" x 99¾"
[65 cm x 140 cm]
[65 cm x 186 cm]
[65 cm x 200 cm]
[65 cm x 253 cm]
Adjusted Maximum Load Capacity:
1
320 lbs [145 kg]
600 lbs [270 kg]
600 lbs [270 kg]
600 lbs [270 kg]
for load thickness
for load thickness
for load thickness
for load thickness
up to 6" [15 cm]
up to 12" [30 cm]
up to 12" [30 cm]
up to 8" [20 cm]
Maximum Per-Pad Load Capacity: 150 lbs [68 kg]
2
Weight Increase: approx. 20 lbs [9 kg] (includes both T-arm assemblies)
Note: Make sure to add the weight of all options to the lifter weight when you are
selecting appropriate hoisting equipment (see lifter's instruction manual).
1
For loads with thicknesses greater than those listed, please contact Wood's Powr-Grip for help in determining the maximum
load capacity of the lifter.
2
Note that a load capacity calculated from the Maximum Per-Pad Load Capacity may not exceed the Adjusted Maximum Load
Capacity.
