1
Chapter 2
Installation
This Chapter covers the physical installation of the VoIP Gateway.
Requirements
• TCP/IP protocol must be installed on all PCs.
• For Internet Access & VoIP, you must have access to Internet.
Procedure
1. Choose an Installation Site
Select a suitable place on the network to install the VoIP Gateway.
Ensure the VoIP Gateway is powered OFF.
2. Connect LAN Cable
Connect the LAN port of the VoIP Gateway to a router using the standard LAN cable
that is shipped with the VoIP Gateway.
3. Connect Phones
Connect CO lines or PBX extension lines to the FXO ports.
4. Power Up
Connect the supplied power adapter to the VoIP Gateway and power up.
Use only the power adapter provided. Using a different one may cause hardware dam-
age.
5. Check the LEDs
• The Power LED should be ON.
• The LAN LED should be ON.
2
