5
Requirements
Consoles
• A DVI single link or dual link DVI monitor capable of the highest resolution you will be us-
ing on any monitor in the installation.
• A USB keyboard
• A USB mouse
• Stereo microphone and stereo speakers (optional)
Computers
The following equipment must be installed on each computer that is to be connected to the
system:
• A DVI port
• 2 USB ports for the mouse and keyboard
• Microphone and speaker ports (optional)
Cables
• For optimal signal integrity, and to simplify the layout, we strongly recommend that you
use the high quality custom KVM Cable that is provided with this package.
• Cat 5e cable with solid conductors is required to connect the Local and Remote units.
Cable of a lower standard will result in degrading of the video signal. We strongly recom-
mend using Cat 5e or higher grade cables.
• For better quality over longer distances, we suggest using 350MHz Low Skew Cable
with solid conductors.
Maximum Cable Distance
Connection Distance
Computer to Local Unit 16’
Local Unit to Remote Unit via Cat5e cable 200’
Remote Unit (GCE611U / GCE616U) to monitor 16’
