12
Operation
Picture Ajustment
The EQ switch on the unit is designed to adjust the equalization strength and improve a
blinking image.
The values range from 0-7 where:
* 7: strongest equalization
* 0: weakest equalization
LED Display
The GCE611U/ GCE616U Local and Remote Units have front panel LEDs to indicate their
operating status, as shown in the tables, following:
- Local Unit
LED Indication
Link (Green) - Lights steadily to indicate that the connection to the Remote unit is OK.
- Flashes when there is a problem with the connection to the Remote unit.
Power (Green) - Lights steadily to indicate that the Local unit is receiving power.
- Remote Unit
LED Indication
Link (Green) - Lights steadily to indicate that the connection to the Local Unit is OK.
- Flashes when there is a problem with the connection to the Local Unit.
Power (Green) - Lights steadily to indicate that the Remote unit is receiving power.
