26

Drain line - 3/4”

Drain line - 1”

1

15-H4615

Elbow Locking Clip

1

2-8

15-V3008-02

Drain Ftg, 1” Straight Assy.

1

3*

15-V3166

Drain Ftg Body, 1”

1

4*

15-V3167

Drain Ftg Adapter, 1”

1

5*

15-V3163

O-ring 019

1

6*

15-V3150

Split Ring

1

7*

15-V3151

Nut, 1” QC

1

8*

15-V3105

O-ring 215

1

9

15-V3190-090 DLFC 9.0 gpm for 1”

15-V3190-100 DLFC10.0 gpm for 1”

One

15-V3190-110

DLFC 11.0 gpm for 1”

DLFC

15-V3190-130 DLFC 13.0 gpm for 1”

must be

15-V3190-150 DLFC 15.0 gpm for 1”

used if

15-V3190-170 DLFC 17.0 gpm for 1”

1” fitting

15-V3190-200 DLFC 20.0 gpm for 1”

is used

15-V3190-250 DLFC 25.0 gpm for 1”

QTY.

ITEM NO. ORDER NO.

See System Specifications DLFC on page 32, for correct DLFC size for

your unit.

The nuts and caps are designed to be unscrewed or tightened by hand or

with the special plastic wrench. If necessary a pliers can be used to un-

screw the nut or cap. Do not use a pipe wrench to tighten or loosen nuts or

caps. Do not place screwdriver in slots on caps and/or tap with a hammer.

Do not use pipe dope or other sealants on threads. Teflon tape must be

used on threads of the 1” NPT connection and on the threads for the drain

line connection. Teflon tape is not necessary on the nut connection nor

caps because of o-ring seals.

Figure 18

Figure 19

Systems are shipped without 3/4” nut for drain elbow (polytube instal-

lation only) and 5/8” polytube insert (polytube installation only).
See System Specifications DLFC on page 32, for correct DLFC

size for your unit.

1

15-H4615

Elbow Locking Clip

1

2

15-PKP10TS8 Polytube Insert, 5/8”

Option

3

15-V3192

Nut 3/4” Drain Elbow

Option

4-6

15-V3158-01

Drain Elbow 3/4” Male Assy

1

5

15-V3163

O-ring 019

1

6

15-V3159-01

DLFC Retainer Assy.

1

7

15-V3162-007 DLFC 0.7 gpm for 3/4”

1

15-V3162-010 DLFC 1.0 gpm for 3/4”

15-V3162-013 DLFC 1.3 gpm for 3/4”

One

15-V3162-017 DLFC 1.7 gpm for 3/4”

DLFC

15-V3162-022 DLFC 2.2 gpm for 3/4”

must

15-V3162-027 DLFC 2.7 gpm for 3/4”

be used

15-V3162-032 DLFC 3.2 gpm for 3/4”

if 3/4

15-V3162-042 DLFC 4.2 gpm for 3/4”

fitting

15-V3162-053 DLFC 5.3 gpm for 3/4”

is used

15-V3162-065 DLFC 6.5 gpm for 3/4”

15-V3162-075 DLFC 7.5 gpm for 3/4”

QTY.

ITEM NO. ORDER NO.

DESCRIPTION

DESCRIPTION
