12
RELAY 2 TRIGGER

SET
TIME
serviCe reMinDer
STEP 20S – Set scheduled service alarm using  or  buttons. Available options
are OFF, TIME, ON GAL or BOTH. Selecting OFF disables this feature. If OFF is
selected press NEXT to exit System Setup. If TIME, ON GAL or BOTH is selected
press NEXT to select the TIME and/or ON GAL values. See Steps 21S and/or 22S.
Press REGEN to return to the previous step.
STEP 21S – Service alarm for TIME ranges from 0.25 to 9.75 years. Use  or 
buttons to select value. Press NEXT to either exit System Setup or if BOTH was
selected go to Step 22S. Press REGEN to return to the previous step.
STEP 22S – Service alarm for ON GAL ranges from 100 to 9,999,900 gallons. Use
 or  buttons to select value. Press NEXT to exit System Setup. Press REGEN
to return to the previous step.
SERVICE ALARM

SET
BOTH
Step 20S
SCHEDULED SERVICE

SET
0.25
Step 21S
SCHEDULED SERVICE

SET
80000
Step 22S
YR
GAL
Step 19S
If REGEN gallons chosen to activate relay. Relay activates after set number of gallons
have been used in service and if any water is used during regeneration and then deactivates
after set period of time or after flow stops, whichever comes first. Press NEXT to select num-
ber of gallons per relay activation.
STEP 18 S – Use up and down arrows to set number of gallons per relay activation. Range
1-100 gallons. Press NEXT to select duration of relay activation.
STEP 19 S – Use up and down arrows to set duration of relay activation in minutes. Range:
1 second - 500 minutes. Press NEXT to go to Relay 2 Trigger.
Relay 2 programming includes identical options as Relay 1.
RELAY 1 DURATION

SET
0:01
MIN
Step 18S
RELAY 1 SET POINT

SET
REGEN GAL
RELAY 1 SETPOINT

GAL
1
SET
RETURN TO ROTATING DISPLAY
RETURN TO ROTATING DISPLAY
