5
WARMER DRAWER
P/N 1011027 Rev. E 06/10
SPECIFICATIONS
A B
C
Model &
Mfg. No.
Width
(A)
Depth
(B)
Height
(C)
Operating
Weight
Shipping
Weight
WD-50
9400162
9400165
32 1/2"
(826 mm)
21 7/8"
(556 mm)
5 3/8"
(137 mm)
62 lbs.
(28 kg)
68 lbs.
(31 kg)
WD-50
9400166
9400167
32 1/2”
(826 mm)
21 7/8”
(556 mm)
5 3/8”
(137 mm)
64 lbs.
(29 kg)
70 lbs.
(32 kg)
Model &
Mfg. No.
Volt Watts Amps Hz
Plug
Description
Plug
Configuration
WD-50
9400162
9400165
9400166
9400167
120 1400 11.7 50/60
5-15P, 15
Amp., 250 VAC
WHT BLK
GRN
WD-50 One 2-1/2” (65 mm) deep 2/3-size pan and
two 2-1/2” (65 mm) deep 1/3-size pans.
Holds 60-80 standard size hot dogs.
NOTE: Units with Manufacturing Number 9400165
do not include serving pans or the top Heat Shield.
Capacity
Electrical Ratings and Plug Configuration
Dimensions
