A.J. Antunes & Co WD-50 9400167 - Manual (Page 13)

13
WARMER DRAWER
P/N 1011027 Rev. E 06/10
REPLACEMENT PARTS (continued)
1 2130181** 2/3-Size Pan, 2.5” Dp. 1
2 2130182** 1/3-Size Pan, 2.5” Dp. 2
3 0505866** Pan Bottom, 1/3-Size 2
4 0505865** Pan Bottom, 2/3-Size 1
5 0021594 Drawer Weldment 1
6 0505862 Pan Divider 2
8 2100318 Handle, Drawer 1
9 4030412 Thermometer 1
10 0400398 Grommet (not shown) 1
11 4030415 Heating Element 1
12 2110193 Clip, Heating Element 3
13 4030189 Thermostat, 300°F 1
14 0504627 Inner Liner, Top/Back 1
15 0505982 Probe Retainer Bracket 1
16 4010228 Power Switch 1
17 0504619 Cover Weldment 1
18 4060355 Terminal Block, 3 Pole 1
19 4070144 Elec. Thermostat Assembly 1
20 2100322 Knob, Thermostat 1
21 4050214 Thermostat Probe, 315°F 1
(Not Shown)
22 0504618 Rear Panel 1
23 0504626 Bottom Weldment 1
24 2120148 Brass Spacer 3
26 0021596* Heat Shield Weldment 1
27 2100195 Roller Bearing 4
28 0504264 Lock Lever, Left 1
29 0504266 Lock Lever, Right 1
30 0504265 Spacer 2
31 0700463 Power Cord, 14/3 5-15P 1
32 0504623 Front Drawer Panel 1
35 0400354 Strain Relief Elbow (not shown) 1
36* 306P130 Nut, Hex KEPS #6-32 1
37* 308P103 Screw, #8-32 x 1/4” Sltrshd 1
38* 308P133 Screw, #8-32 x 1/4” Panhd 1
39* 306P113 Screw, #6-32 x 5/8” Slrndhd 1
41* 3310115 Shcap 5/16-18 x 7/8” Lg. 1
42* 306P101 Nut, Hex #6-32 1
*Available only in packages of 10
** Not included with Mfg. No. 9400165
Item Part Description Qty.
No.
Item Part Description Qty.
No.
