Media Technology Systems ION8.8 - Manual (Page 5)

Page 5 of 31 Aug‐09
Table of Contents
1 WELCOME 6
1.1 I MPORTANT S AFETY I NSTRUCTIONS 6
1.2 H OW TO USE THIS MANUAL . 6
1.3 T ERMINOLOGY : F UNCTIONS , N AMES & A CRONYMS . 7
2 SPECIFICATIONS 9
3 FUNCTIONAL DESCRIPTION 10
3.1 S IGNAL P ATH 10
3.2 A NALOG S ECTION 10
3.3 D IGITAL SECTION 10
3.4 P OWER S UPPLY 12
3.5 I NSTALLING THE I NTERFACE 12
3.6 S ETUP 15
3.7 I NPUT W IRE AND C ONNECTORS : 15
3.8 G ROUND P IN 16
3.9 N ETWORK CONNECTIONS 16
4 CONTROL PORTS 17
4.1 C OBRA N ET ™ 17
4.2 E THERNET 17
4.2.1 GUI DEFAULT PAGE 18
4.2.2 S YSTEM SETTINGS 19
4.2.3 C OBRA N ET ™ SETTINGS 21
4.2.4 DSP SETTINGS 23
4.2.5 S NIFFING MAC/IP ADDRESS 28
5 MTSI WARRANTY: UNITED STATES & CANADA 29
6 INDEX 31
