MAXIM Installation Instructions
© Mass Electronics Pty Ltd 2011
Chapter 3 – Electrical Installation
A single transformer may be used to supply voltage to more than one controller, but you must ensure
that the planned load is well within the rating of the transformer. The transformer output terminal
designated as AC Neutral must be solidly earthed to the main earth link of the enclosure panel. The
dedicated power input terminals are Terminals 1 and 2 and are detailed in Table 3-14 below.
Table 3-14:
IG01 Sub System Gateway Power Terminals
Terminal
AC Supply
DC Supply
1
24VAC
24VDC
2
0VAC (Neutral)
0VDC
