5.4 Remote Interface
5.4.1 Connections:
Table 5-4 Remote TB = TBR (located in remote enclosure); J5 (located on main PC board)
TBR:1 to J5:1
TBR:2 to J5:2
TBR:3 to J5:3
TBR:4 to J5:4
TBR:5 to J5:5
TBR:6 to J5:6
TBR:7,14 to J5:7
TBR:8 NC
TBR:9 to J5:9
TBR:10 to J5:10
TBR:11 to J5:11
TBR:12 to J5:12
TBR:13 to J5:13
5.5 Interface
J4:1 Lockout Signal
J4:2 Lockout Common
J4:3 Part Release Common
J4:4 Part Release NO
J4:5 Part Release NC
J4:6 Current Sense Common
J4:7 Current Sense NO
J4:8 Current Sense NC
